Electrocompaniet ECP 2 Phono Pre Amp - Pre Loved
The Electrocompaniet ECP 2 is a world-class phono stage engineered to extract every ounce of musical detail from your vinyl collection. Handcrafted in Norway, it combines precision circuitry, an ultra-low noise floor, and exceptionally accurate RIAA equalisation. Suitable for both Moving Magnet and Moving Coil cartridges, the ECP 2 offers extensive gain and loading adjustments to perfectly match any cartridge. With its elegant design, wide dynamic range, and musical presentation, the ECP 2 brings warmth, depth, and realism to analogue playback at the highest level.
This product comes with a 6 month warranty.
Packaging is included but shipping is at extra cost.
| Feature | Specification |
|---|---|
| Type | MM & MC Phono Pre-Amplifier |
| Gain (RCA) | Adjustable 39.8 – 71.4 dB |
| Gain (XLR) | Adjustable 45.8 – 76.4 dB |
| Resistance Loading | Adjustable 10 Ω – 47 kΩ |
| Capacitive Loading | Adjustable 0 – 350 pF |
| Maximum Output Level | 17.5 V rms (+25 dBV) |
| Overload Margin | > 31 dB @ 1 kHz |
| Output Impedance | 100 Ω (RCA), 200 Ω (XLR) |
| Frequency Response | 20 Hz – 20 kHz (±0.2 dB) |
| RIAA Accuracy | ±0.1 dB |
| Subsonic Filter | –3 dB @ 11 Hz, 24 dB/octave |
| Channel Separation | > 85 dB (20 Hz – 20 kHz) |
| THD + Noise | < 0.003 % @ 1 kHz |
| Signal-to-Noise Ratio (10 dBV out) | 96 dB, A-weighted |
| Signal-to-Noise Ratio (5 mV input) | 91 dB, A-weighted |
| Signal-to-Noise Ratio (500 µV input) | 67.4 dB, A-weighted |
| Power Supply | External linear supply |
| Dimensions (W × H × D) | 465 × 78 × 371 mm |
| Weight | 9 kg |
| Country of Manufacture | Norway |
